SinoTruk Automotive Engine

The automotive engine developed through dual-track advancements based on German MAN technology and the Steyr platform, has established a comprehensive product portfolio encompassing multiple models including MC04, MC05/05H, MC07/07H, MC11/11H, MC13/13H, D10, and D12. With a broad power range spanning 147kW to 444kW, these engines comprehensively meet the power requirements for various commercial vehicles, including medium- and heavy-duty trucks and buses. Incorporating advanced technologies such as high-pressure common rail and intelligent electronic control, the products comply with China VI emission standards, delivering both high performance and low emissions.

Advantages of Automotive Engine

  • Utilizing German MAN technology with reinforced critical components ensures long-term stable operation.
  • Optimized combustion system achieves a minimum fuel consumption of 180g/kWh, significantly reducing operating costs.
  • This engine series demonstrates exceptional environmental adaptability, guaranteeing stable all-weather operation even under extreme conditions.
  • German intelligent production lines provide full-process monitoring, while modular design minimizes potential failure points.

DuraMac

DCEC ISL8.9 series automotive engine is four-strokes engine with 114 mm bore and 145 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 270 HP to 400 HP.

FIND MORE

Fast Gear

The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.

FIND MORE

EV Truck

Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.

FIND MORE

DANA Axle

Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.

FIND MORE

Datong Gear

The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

All Wheel Drive Off-road Chassis

Dongfeng Special Vehicle's all-wheel-drive off-road chassis series, developed based on military technology platforms, supports 4×4/6×6 drive configurations and delivers exceptional cross-country capability, high reliability, and strong environmental adaptability. DuraMac provides customized off-road solutions, with products widely applied in high-altitude rescue, wilderness exploration, special transport, and military applications, meeting the demands of both domestic and international specialty vehicle markets.

FIND MORE

Medium & Heavy-duty Truck

DuraMac offers a full range of Dongfeng solutions for medium-to-heavy-duty trucks, covering diesel, pure electric, and hydrogen fuel cell powertrains. Its pure electric trucks feature high-energy-density batteries and electric drive systems with dual-gun fast charging capability, ensuring high operational efficiency. Hydrogen-powered heavy-duty trucks are equipped with an intelligent VCU control system and offer multiple power variants. All products utilize high-strength chassis and IP68-rated electrical systems, meeting diverse operational demands across engineering transport, port logistics, and urban distribution.

FIND MORE

Steyr WD615 Automotive175-273 kW
Steyr D10 Automotive206-276 kW
Steyr D12 Automotive279-309 kW
Steyr T12 Automotive279-309 kW
MAN MC03 Automotive115-125 kW
MAN MC04 Automotive125-145 kW
MAN MC05 Automotive103-180 kW
MAN MC07 Automotive151-258 kW
MAN MC11 Automotive231-363 kW
MAN MC13 Automotive341-444 kW
MAN MT07 Automotive162-213 kW
MAN MT13 Automotive265-316 kW

Engine Model

Power/kW

080160240320400480560
SionTruk Automotive Engine Catalogue
Series
Model



WD615.44 | 235 kW @ 2200 RPMWD615.46 | 266 kW @ 2200 RPMWD615.47 | 273 kW @ 2200 RPMWD615.50 | 203 kW @ 2200 RPM
WD615.56 | 193 kW @ 2200 RPMWD615.58 | 175 kW @ 2200 RPMWD615.62 | 196 kW @ 2200 RPMWD615.69 | 247 kW @ 2200 RPM
WD615.87 | 213 kW @ 2200 RPM
D10.27-31 | 198 kW @ 1900 RPMD10.28-50 | 206 kW @ 1900 RPMD10.29-31 | 213 kW @ 1900 RPMD10.31-50 | 228 kW @ 1900 RPM
D10.34-31 | 249 kW @ 1900 RPMD10.34-50 | 249 kW @ 1900 RPMD10.38-30 | 279 kW @ 2000 RPMD10.38-50 | 276 kW @ 2000 RPM
D12.38 | 279 kW @ 2000 RPMD12.42 | 309 kW @ 2000 RPM
T12.38-40 | 279 kW @ 2000 RPMT12.42-40 | 309 kW @ 2000 RPM
MC03 | 115 kW @ 3000 RPMMC31 | 125 kW @ 2800 RPM
MC04 | 125 kW @ 2600 RPMMC41 | 145 kW @ 2600 RPMMC45 | 162 kW @ 2300 RPMMT45 | 145 kW @ 2300 RPM
MC05.14-30 | 103 kW @ 2400 RPMMC05.16-30 | 118 kW @ 2400 RPMMC05.18-30 | 132 kW @ 2400 RPMMC05.21-30 | 151 kW @ 2400 RPM
MC05.14-50 | 103 kW @ 2400 RPMMC05.16-50 | 118 kW @ 2400 RPMMC05.18-50 | 132 kW @ 2400 RPMMC05.21-50 | 151 kW @ 2400 RPM
MC05H.20-50 | 147 kW @ 2200 RPMMC05H.23-50 | 166 kW @ 2200 RPMMC05H.25-50 | 180 kW @ 2200 RPMMC05H.20-60 | 147 kW @ 2200 RPM
MC05H.23-60 | 166 kW @ 2200 RPMMC05H.25-60 | 180 kW @ 2200 RPM
MC07.21-30 | 151 kW @ 2300 RPMMC07.24-30 | 176 kW @ 2300 RPMMC07.28-30 | 206 kW @ 2300 RPMMC07.31-30 | 228 kW @ 2300 RPM
MC07.33-30 | 240 kW @ 2300 RPMMC07.34-30 | 248 kW @ 2300 RPMMC07.21-50 | 151 kW @ 2300 RPMMC07.24-50 | 176 kW @ 2300 RPM
MC07.28-50 | 206 kW @ 2300 RPMMC07.31-50 | 228 kW @ 2300 RPMMC07.33-50 | 240 kW @ 2300 RPMMC07.34-50 | 248 kW @ 2300 RPM
MC07.35-50 | 254 kW @ 2300 RPMMC07.25-61 | 190 kW @ 2300 RPMMC07.27-61 | 202 kW @ 2300 RPMMC07.29-61 | 213 kW @ 2300 RPM
MC07H.29-50 | 213 kW @ 2200 RPMMC07H.32-50 | 235 kW @ 2200 RPMMC07H.35-50 | 257 kW @ 2200 RPMMC07H.27-61 | 176 kW @ 2200 RPM
MC07H.29-61 | 213 kW @ 2200 RPMMC07H.31-61 | 228 kW @ 2200 RPMMC07H.33-61 | 240 kW @ 2200 RPMMC07H.33-61 | 240 kW @ 2200 RPM
MC07H.35-61 | 254 kW @ 2200 RPMMC07H.35P-61 | 258 kW @ 2200 RPM
MC11.31-30 | 231 kW @ 1900 RPMMC11.35-30 | 260 kW @ 1900 RPMMC11.39-30 | 290 kW @ 1900 RPMMC11.43-30 | 319 kW @ 1900 RPM
MC11.32-50 | 238 kW @ 1900 RPMMC11.36-50 | 268 kW @ 1900 RPMMC11.40-50 | 291 kW @ 1900 RPMMC11.44-50 | 327 kW @ 1900 RPM
MC11.46-50 | 341 kW @ 1900 RPMMC11.40-61 | 297 kW @ 1900 RPMMC11.43-61 | 319 kW @ 1900 RPMMC11.46-61 | 341 kW @ 1900 RPM
MC11H.46-50 | 341 kW @ 1900 RPMMC11H.49-50 | 363 kW @ 1900 RPMMC11H.40-61 | 297 kW @ 1900 RPMMC11H.43-61 | 319 kW @ 1900 RPM
MC11H.46T-61 | 341 kW @ 1900 RPMMC11H.49-61 | 363 kW @ 1900 RPM
MC13.46-50 | 341 kW @ 1900 RPMMC13.48-50 | 356 kW @ 1900 RPMMC13.50-50 | 371 kW @ 1900 RPMMC13.51-50 | 378 kW @ 1900 RPM
MC13.54-50 | 400 kW @ 1900 RPMMC13.46-61 | 341 kW @ 1800 RPMMC13.48-61 | 356 kW @ 1800 RPMMC13.50-61 | 371 kW @ 1800 RPM
MC13.54-61 | 400 kW @ 1800 RPMMC13H.48-61 | 356 kW @ 1800 RPMMC13H.51-61 | 378 kW @ 1800 RPMMC13H.54-61 | 400 kW @ 1800 RPM
MC13H.57-61 | 422 kW @ 1800 RPMMC13H.60-61 | 444 kW @ 1800 RPM
MT07.22-50 | 162 kW @ 2300 RPMMT07.24-50 | 176 kW @ 2300 RPMMT07.26-50 | 191 kW @ 2300 RPMMT07.29-50 | 216 kW @ 2300 RPM
MT07.24-60 | 176 kW @ 2200 RPMMT07.26-60 | 191 kW @ 2200 RPMMT07.29-60 | 213 kW @ 2200 RPM
MT13.36-50 | 265 kW @ 1900 RPMMT13.40-50 | 294 kW @ 1900 RPMMT13.43-50 | 316 kW @ 1900 RPM
——END——

Find Automotive Engines by Series

This is the list of all series of SinoTruk autmotive engines.
